Description
♦ Welding range: 63mm – 1200mm (2″ – 48″ IPS)
♦ Power supply: 220V / 380V, 50–60Hz
♦ Minimum order quantity: 1 set
♦ Bulk order discounts: Available
♦ Payment terms: T/T, Western Union
Application – Butt Fusion Welding Procedure
1. Material Preparation
Ensure pipes and fittings are of the same diameter, grade, and material. Any welding between different grades or materials must be tested before use.
2. Pipe Clamping
Clean pipe ends thoroughly. Secure pipes in the machine clamps with equal protrusion on both sides. Support external pipe lengths to maintain proper alignment with the machine centerline.
3. Facing (Cutting)
Use the planing tool to face both pipe ends until continuous shavings appear. Recommended shaving thickness is 0.5–1.0 mm, ensuring clean and smooth end faces.
4. Alignment
Pipe misalignment should not exceed 10% of wall thickness to prevent stress concentration at the joint.
5. Heating
Insert the heating plate once the set temperature is reached. Apply pressure until a uniform melt bead forms, then reduce pressure to allow proper heat soaking.
6. Changeover
Remove the heating plate quickly. Shorter changeover times result in stronger fusion joints.
7. Fusion Joining
Join the pipe ends under controlled pressure. Maintain pressure throughout the fusion process.
8. Cooling
Allow the joint to cool under pressure. Due to the low thermal conductivity of thermoplastics, cooling must be gradual to ensure joint strength and structural stability.
HDPE Welding Machine Models & Specifications (Summary)
| Model | Welding Range (mm) | Power Supply | Total Power | Weight |
|---|---|---|---|---|
| SPH160 | 63–160 | 220V | 2.46 kW | 110 kg |
| SPH200 | 63–200 | 220V | 3.06 kW | 120 kg |
| SPH250 | 90–250 | 220V | 3.85 kW | 145 kg |
| SPH315 | 160–315 | 220V | 4.95 kW | 190 kg |
| SPH450 | 280–450 | 380V | 8.22 kW | 400 kg |
| SPH630 | 400–630 | 380V | 12.22 kW | 630 kg |
| SPH800 | 630–800 | 380V | 15.8 kW | 1200 kg |
| SPH1000 | 800–1000 | 380V | 22.4 kW | 1950 kg |
All machines are supplied with non-stick coated heating plates, German hydraulic seals, and high-quality electrical components.
Advantages of Hydraulic Butt Fusion Welding Machines
-
Suitable for welding PE, PP, PB, and PVDF pipes and fittings
-
Designed for on-site and trench installation
-
Complete system including main frame, planing tool, heating plate, and support stand
-
Manufactured using lightweight, high-strength materials
-
Labor-saving design with high efficiency
-
Main structural components made from pure aluminum, offering durability, smooth operation, and reduced weight
